For full details on this hardware (including installation, current specifications, etc) please refer to the Solutions Document.

The CladWall system is primarily designed for 1/8" guage Varia Ecoresin panels in a grid with clean consisten reveals between the panels.

CladWall gauges

The CladWall system grid can be configured to almost any panel size to optimize the material. Individual tile size should be limited to approximately 16 sq. ft. The overall grid or wall size is practically limitless and can be attached to most surfaces such as drywall, wood, concrete or CMU. Inside/Outside corners are achieved by aligning the edge profiles of each wall grid at the corner. CladWall is not designed to be used for ceilings or overhead surfaces.

Box Wall Volume and Free Standing examples


Inside/Outside Corner Alignment

Horizontal Section View
